Product Detail

MT8101IP

WEINTEK MT8101IP

Product Brief Description

Display



Display: 4.3" TFT LCD

Resolution: 480X272

Brightness: 400

Contrast Ratio: 500:1

Backlight Type: LED

Backlight Life Time: >30,000hrs.

Colors: 16.7M

LED Viewing Angle(T/B/L/R): 50/70/70/70

Touch Panel

Type: 4-wire Resistive Type

Accuracy: Active Area Length(X)±2%,width(Y)±2%

Memory

Flash: 128MB

RAM:128MB

Processor

32 bits RISC Cortex-A8 600MHz

I/O Ports

USB Host: USB 2.0X1

USB Client: N/A

Ethernet: 10/100 Base-T x 1

COM Port: COM1:RS-232/RS-485 2W/4W

                 COM2:RS-485 2W

RTC

Built-in(CR2032 3V lithium battery.)

Power

Input Power: 24±20%VDC

Power Isolation: Built-in

Power Consumption: 400mA@24VDC

Voltage Resistance: 500VAC(1 min.)

Isolation Resistance: Exceed 50MΩ at 500VDC

Vibration Endurance: 10 to 25Hz(X,Y,Z direction 2G 30 minutes)

Specification

PCB Coating: N/A

Enclosure: Plastic

Dimensions WxHxD:128X102X32mm

Panel Cutout: 119X93mm

Weight: Approx. 0.25 kg

Mount: Panel mount

Environment

Protection Structure: NEMA4/IP65 Compliant Front Panel

Storage Temperature: -20°~60°C(-4°~140°F)

Operating Temperature: 0°~50°C(32°~122°F)

Relative Humidity: 10%~90%(non-condensing)

Software

EasyBuilder Pro

Display



Display: 4.3" TFT LCD

Resolution: 480X272

Brightness: 400

Contrast Ratio: 500:1

Backlight Type: LED

Backlight Life Time: >30,000hrs.

Colors: 16.7M

LED Viewing Angle(T/B/L/R): 50/70/70/70

Touch Panel

Type: 4-wire Resistive Type

Accuracy: Active Area Length(X)±2%,width(Y)±2%

Memory

Flash: 128MB

RAM:128MB

Processor

32 bits RISC Cortex-A8 600MHz

I/O Ports

USB Host: USB 2.0X1

USB Client: N/A

Ethernet: 10/100 Base-T x 1

COM Port: COM1:RS-232/RS-485 2W/4W

                 COM2:RS-485 2W

RTC

Built-in(CR2032 3V lithium battery.)

Power

Input Power: 24±20%VDC

Power Isolation: Built-in

Power Consumption: 400mA@24VDC

Voltage Resistance: 500VAC(1 min.)

Isolation Resistance: Exceed 50MΩ at 500VDC

Vibration Endurance: 10 to 25Hz(X,Y,Z direction 2G 30 minutes)

Specification

PCB Coating: N/A

Enclosure: Plastic

Dimensions WxHxD:128X102X32mm

Panel Cutout: 119X93mm

Weight: Approx. 0.25 kg

Mount: Panel mount

Environment

Protection Structure: NEMA4/IP65 Compliant Front Panel

Storage Temperature: -20°~60°C(-4°~140°F)

Operating Temperature: 0°~50°C(32°~122°F)

Relative Humidity: 10%~90%(non-condensing)

Software

EasyBuilder Pro
